Amongst the most compact on the market, our Spark II wood stove can heat up to 1,200 ft² with a maximum heat output of 45,000 BTU/h. Non-catalytic and CSA certified at 1.8 g/h, this model can efficiently heat small spaces. The bottom of its combustion chamber is deeper than other models in its category and allows a greater accumulation of ashes, and thus to be able to empty them much less frequently. Packaged in a rigid cardboard box for ease of transport, this appliance requires simple assembly.
Features
- Up to 5 hours burn time
- Up to 17″ logs
- 1.55 ft³ firebox
- CSA certified
- Limited lifetime warranty
- Certified for mobile home and alcove installation
Specifications
| Approved for alcove installation | Yes |
| Approved for mobile home installation | Yes |
| Type of door | Simple, glazed or not, with cast iron frame |
| Type of glass | Ceramic glass |
| Blower | Optional (up to 100 CFM) |
| Particulate emission standard | EPA / CSA B415.1-10 |
| USA standard | (Safety) UL 1482, UL 737 |
| Size | 18 1/2″ W X 28 7/8″ D X 28 3/4″ H |
| Combustion type | Non-catalytic |
| Fuel Type | Dry Cordwood |
| Recommended heating area (sq. ft.. ) | 1 250 to 1,200 ft2 (23 to 111 m2) |
| Total firebox volume | 1.7 ft3 (0.0481 m3) |
| EPA loading volume | 1.55 ft3 (0.0439 m3) |
| Maximum burn time | 5 hours |
| Maximum heat output (dry cordwood) | 45,000 BTU/h (13.2 kW) |
| Overall heat output rate (min. to max.) | 12,124 BTU/h to 26,700 BTU/h (3.55 kW to 7.83 kW) |
| Average overall efficiency (Dry cordwood) | 74 % (HHV) 79 % (LVH) |
| Optimum efficiency | 80 % |
| Optimum heat transfer efficiency | 79 % |
| Average particulate emissions rate | 1.8 g/h (EPA / CSA B415.1-10) |
| Average CO | 74 g/h |
| Maximum log length | 17 in (432 mm) north-south |
| Flue outlet diameter | 6 in (150 mm) |
| Recommended connector pipe diameter | 6 in (150 mm) |
| Type of chimney | ULC-S629, UL 103 HT (2100 °F) |
| Minimum chimney height | 12 feet |
| Baffle material | Vermiculite |
Package Contents
Wood stove
Steel legs
Air deflector
Ceramic glass
Cast iron door with adjustable hinges
Ash lip
Air damper
